Plate evaporator
The plate evaporator holds an important position in industrial evaporation equipment, widely applied due to its unique design and principle. Henan Jiuyue Chemical Equipment Co., Ltd. possesses rich experience in its research and manufacturing.
The equipment comprises a plate heat exchanger and a separator. The heat exchanger is constructed from metal plates with special corrugation, arranged in layers where heating and product plates alternate to create the heating and product channels, enhancing heat transfer through counter-current flow between the product and heating medium. The plate group is installed between a fixed plate and a movable plate, secured with screws, and utilizes non-glue embedded gaskets for sealing, facilitating installation and disassembly. The separator is responsible for the efficient separation of the vapor-liquid mixture produced during evaporation.
Operational Principle
The material to be evaporated enters the evaporator, flowing between the plates of the plate heat exchanger, where the external heating medium transfers heat through the plates. The special corrugation creates high-intensity turbulence in the material, increasing the heat transfer coefficient, allowing for rapid evaporation of the material and the formation of different liquid films based on the type of evaporator. The vapor-liquid mixture enters the separator and is separated through centrifugal force and other actions, with the concentrated material being discharged from the bottom and secondary steam being expelled from the top, which can be recycled in multi-effect evaporation or MVR systems.
Operational Principle
The material to be evaporated enters the evaporator, flowing between the plates of the plate heat exchanger, where the external heating medium transfers heat through the plates. The special corrugation creates high-intensity turbulence in the material, increasing the heat transfer coefficient, allowing for rapid evaporation of the material and the formation of different liquid films based on the type of evaporator. The vapor-liquid mixture enters the separator and is separated through centrifugal force and other actions, with the concentrated material being discharged from the bottom and secondary steam being expelled from the top, which can be recycled in multi-effect evaporation or MVR systems.
01: Energy-efficient and high-performance
The counterflow heat exchange fully utilizes the temperature difference, achieving a heat transfer coefficient several times higher than that of traditional shell-and-tube evaporators. It can operate under a temperature difference of 3-5℃, reducing steam consumption, and can save compressor power when applied in MVR systems.
02: Adaptable to complex materials
The material flow rate is controllable, allowing turbulence formation at low flow rates. It is suitable for materials containing small amounts of insoluble solids, high viscosity, and heat-sensitive materials, with short residence time to reduce the risk of deterioration.
03: High operational flexibility
Adjustable circulation pumps and heating medium flow rates allow for flexible adjustments of evaporation intensity and concentration ratios, meeting various production process needs.
04: High heat transfer efficiency
The high-speed flow of the solution reduces the thickness of the heat transfer boundary layer, resulting in a heat transfer efficiency that surpasses that of natural circulation evaporators, meeting large-scale production capacity requirements.
05: High degree of automation
Equipped with an automated control system, it monitors and adjusts parameters such as temperature and pressure in real-time. Operators can control the system from the control room, ensuring stable and reliable production.
The counterflow heat exchange fully utilizes the temperature difference, achieving a heat transfer coefficient several times higher than that of traditional shell-and-tube evaporators. It can operate under a temperature difference of 3-5℃, reducing steam consumption, and can save compressor power when applied in MVR systems.
02: Adaptable to complex materials
The material flow rate is controllable, allowing turbulence formation at low flow rates. It is suitable for materials containing small amounts of insoluble solids, high viscosity, and heat-sensitive materials, with short residence time to reduce the risk of deterioration.
03: High operational flexibility
Adjustable circulation pumps and heating medium flow rates allow for flexible adjustments of evaporation intensity and concentration ratios, meeting various production process needs.
04: High heat transfer efficiency
The high-speed flow of the solution reduces the thickness of the heat transfer boundary layer, resulting in a heat transfer efficiency that surpasses that of natural circulation evaporators, meeting large-scale production capacity requirements.
05: High degree of automation
Equipped with an automated control system, it monitors and adjusts parameters such as temperature and pressure in real-time. Operators can control the system from the control room, ensuring stable and reliable production.
01: Chemical IndustryUsed for the production of caustic soda, soda ash, and the separation and purification of products from organic chemical reactions.
02: Energy IndustryUsed for the condensation of waste steam in waste heat recovery systems, improving energy utilization efficiency.
03: Food and Beverage IndustryConcentrated fruit juices, syrups, etc., low-temperature evaporation to preserve product quality.
04: Environmental Protection FieldTreatment of high-concentration organic wastewater, saline wastewater, and industrial waste gas absorption liquid.
05: Pharmaceutical IndustryUsed for the concentration, crystallization, and solvent recovery of drug intermediates.
The plate evaporator from Jiuyao Chemical offers efficient evaporation solutions for various industries with advanced technology, exceptional performance, and wide applicability, contributing to efficient and sustainable industrial development.
Henan Jiuyue Chemical Equipment Co., Ltd. was established in 1999 and is a comprehensive high-tech enterprise that integrates scientific research, design, manufacturing, installation, and service. It is recognized as a specialized, refined, distinctive, and innovative small giant enterprise in Henan Province. The company primarily engages in the design, manufacture, and installation of pressure vessels, various evaporators, chemical tanks, towers, and bioreactor equipment. The leading product, various types of evaporators, is widely used in industries such as alumina, papermaking, sewage treatment, biochemistry, food, chemicals, pharmaceuticals, and salt production. Notably, the energy-saving seven-effect two-stage falling film evaporator technology is at the world-leading level, and the company holds over 30 patents for the evaporators and related equipment. Throughout the company's development, its products have successfully entered major alumina enterprises including Weiqiao Aluminum, Xinfa Group, China Aluminum Group, Jinjiang Group, Rusal Group, Guangxin Aluminum Group, Jiugang Group, Tiangu Aluminum, Guizhou Qiya, Lubeh Chemical Group, and Zhongchao Aluminum, earning a strong reputation. Additionally, our products have also been successfully applied in overseas markets, such as the Rusal Kenya project, Jiugang Jamaica project, and Jinjiang and China Aluminum projects in Indonesia, achieving broad market reach and a positive social reputation.
